Fan Filter Unit for Clean Room

fan filter units (FFU) for clean room 1.introduce of the fan filter units fan filter units adopts imported anti-static MULTI wing type fan-type fan,with three wind speed control switch: high , medium and low-grade .and have big air volume, low noise for 45 decibels, up to 52 decibels. wind...

InquiryChat Now

  • Product Details

fan filter units (FFU) for clean room

1.introduce of the fan filter units

fan filter units adopts imported anti-static MULTI wing type fan-type fan,with three wind speed control switch:  high , medium and low-grade .and  have big air volume, low noise for 45 decibels, up to 52 decibels. wind pressure spread evenly. to uniform stability. power consumption cost is low. Fan filter units are a kind of modular end air supply device with power and filtration efficiency.The air is inhaled from the top of the FFU and filtered by HEPA,after filtration evenly distributed through the air at 0.45m/s

2.Regular size and parameter of the fan filter units :



Model

XN-FFU-122S/122Z

XN--FFU-117S/117Z

XN-FFU-61S/61Z

XN-FFU-57S/57Z

Rate air flow(m3/h)

2000

1800

1000

900

Noise (dB)

45~60

Efficiency

≥99.99%~99.9995%(@≥0.3um)

Power

AC220v  50HZ

Overall size
W*L*H  (mm)

1220*610*390

1170*570*340

610*610*390

570*570*340

HEPA filter size
     W*L*H  (mm)

1220*610*69

1170*570*69

610*610*69

570*570*69

Coarse filter size
W*L*H  (mm)

495*495*21

495*495*21

395*395*21

395*395*21

  Input power
(W)

180W

180W

145W

75W

except for standard machines, non-standard products also can be made according to customers requirements

 3.Features and applications of the fan filter units
 Features:
 ●Low running cost and easy to use
 ●Compact structure and environmental friendly
 ●Suitable for use in clean room of class1 to class 1000.
 ●High performance and low noise ,Low vibration fans
 ● Uniform wind speed and adjustable fan
 ●Fan box and  filter can be divided and easy to replacement
 ●frame material are ALZINC frame , stainless steel(SUS304) frame , cold plate spraying frame

Application:
 fan filter  units can use modular connecting , fan filter units are widely used in the clean room, Clean Booth Station ,clean work station, clean production lines, packaged applications, laboratories, medical facilities ,local 100 class occasion etc.

4.details of the fan filter units






  ●FFU laminar is equipped with initial and efficient two-stage filter: The air is inhaled from the top of the FFU and filtered through the initial and high efficiency filter.  after filtration the air out evenly  delivered at a constant speed of 0.45m/s
 ●Beautiful appearance, humanized design: with stainless steel handle can easy to install and move, corner Angle design, no indentation bend
 ●Multiple safety protection :Touch control board, no mechanical button switch, single - key induction, safe and reliable, over current, over pressure, overheat protection


5.Authorized certification




6.FAQ

Q: is there any after-sale service you have provide?

A: we'll take photos for you check before loading container and confirm all of documents within 48 hours after shipment  ,we'll do this favor to arrange everything very well

Q: What is your terms of payment?
A: 50%contract value will be paid by T/T as deposit, and the balance will be paid before the delivery.and we'll show you the photos of the products and packages before you pay the balance.
Q: What about your  delivery time ?
A: Generally, it will take 7-15 working days after receiving your the specific delivery time depends on the items and the quantity of your order.
